Structure Introduction
1、The transformer is divided into single-phase transformer, EI type core dry type.
2、The core uses high quality low loss cold rolled oriented silicon steel sheet, the main material for
0.3 and 0.35 thick H18, H14, H12, Z11 high quality silicon steel sheet, we according to the customer’s
requirements and conditions of use, choose the most suitable material, so that the transformer
performance design to achieve the best!
3、Coils are all wound with H-class enameled wire, tightly and evenly hooked, the appearance of the
insulation layer is not wrapped, with excellent aesthetics, and has a better heat dissipation performance.
4、After assembling the transformer coil and iron core into one piece, it goes through the process of
pre-baking, vacuum dipping paint and hot baking curing, and adopts H grade impregnating paint to
make the transformer coil and iron core firmly combined together, which not only greatly reduces the
noise of the operation but also ensures that the transformer can be operated safely and noiselessly
under high temperature with very high heat-resistant grade.
5、Transformer core column part fasteners pro-use non-magnetic materials, to ensure that the
transformer has a higher quality factor and lower temperature to ensure that has a good filtering effect.
6、Terminal block: small power using Taiwan Mark terminal block, Japan TX terminal, beautiful
appearance, excellent pressure resistance, temperature resistance, flame retardant properties. High
power using high-quality copper.
7、Iron foot: the main use of CNC bending cold rolled plate, there are colorful (gold), blue zinc
(silver), white zinc (ivory), surface treatment (black) and other environmentally friendly plating can be
selected.
8、The transformer and domestic similar products compared with the small size, light weight,
beautiful appearance and other advantages, comparable with foreign famous brands.
