Screw Air Compressor BLT Fixed Frequency Series 5.5-110kW 480V 60Hz

               BLT series technical parameters
Mode l Exhaust pressure

MPa

Exhaust volume
m₃/min
Power

kW

No i se

dB(A)

External dimensions MM TM/TMDD Weight (kg) TM/TMDD Exhaust port pipe diameter inch TM/TMDD
BLT-5A 0.8 0.56 4  62±2 670x675x780 TM 1366x675x1348 140 192 G1/2″ G1/4″
1.0 0.48
BLT-7A 0.8 0.66 5.5  62±2 670×675×780 TM 1686x675x1348 150 225 G1/2″ G1/4″
1.0 0.58
BLT-10A 0.7 1.22 7.5  62±2 960×810×970 TM 1615x935x1632
TMDD    1620x940x1640
210 TM 390
TMDD 430
G3/4″ TM G1″
TMDD G3/4″
0.8 1.20
1.0 0.95
1.3 0.90
BLT-15A 0.7 1.79 11  63±2 850x790x1260 TM 1537x790x1784 293 TM 400 G3/4″ TM G3/4″
0.8 1.78
1.0 1.36 TMDD 1537×790×1784 TMDD 440 TMDD G1″
1.3 1.19
BLT-20A 0.7 2.3 15  63±2 850x790x1260 TM 1565x790x1784 341 TM 410 G3/4″ TM G3/4″
0.8 2.2
1.0 2.0 TMDD    1565x790x1784 TMDD 450 TMDD G1″
1.3 1.5
BLT-25A 0.7 3.0 18.5 64+2 850x790x1260 TM 1565x790x1784 364 TM 430 G1″ TM G3/4″
0.8 3.0
1.0 2.6 TMDD    1565x790x1784 TMDD 470 TMDD G1″
1.3 2.1
BLT-30AG 0.7 3.7 22 64+2 1150x850x1000 436 G1″
0.8 3.5
1.0 3.0
BLT-30A 1.3 2.4 850x790x1260 364
BLT-40AG 0.7 5.4 30  65±2 1430x950x1200 559 G11/2″
0.8 5.0
1.0 4.5
BLT-40A 1.3 3.7
Model Exhaust pressure

MPa

Exhaust volume
m₃/min
Power

kW

Noise

dB(A)

External dimensions
mm
Weight

kg

Exhaust port
pipe diameter
Inlet and outlet pipe
diameter
BLT-50AG 0.7 6.2 37 65±2 1430x950x1200 614 G11/2″
0.8 6.1
1.0 5.1
BLT-60AG 0.7 8.4 45 69±2 1720×980×1600 870 G11/2″
0.8 8.0
1.0 7.4
1.3 6.4
BLT-60W 1.0 6.5 45 69±2 1300×1000×1345 1100 G11/2″ G1″
BLT-75AGWG 0.7 10.5 55 72±2 1950×1060×1600Air-cooled
1819×1060×1596water-cooled
1220/1250 G2″Air-cooled
G11/2″water-cooled
G1″
0.8 10.0
1.0 9.1
1.3 7.8
BLT-100AGWG 0.7 13.6 75 73±2 1950x1060x1600Air-cooled
1819×1060×1596water-cooled
1285/1300 G2″Air-cooled
G11/2″water-cooled
G1″
0.8 13.0
1.0 11.8
1.3 10.3
BLT-120AW 0.7 17.1 90 73±2 2260×1060x1600Air-cooled
1819×1060×1596water-cooled
1570/1620 G2″Air-cooled
G11/2″water-cooled
G1″
0.8 17.0
1.0 15.2
1.3 12.5
